珠海海奇代理商A/B/C/D/E系列產品性能參數選型表
作者：betway必威發布時間：2024-03-05
海奇芯片在多媒體SOC 領域擁有深厚的技術積累和市場理解，產品已廣泛應用于消費電子、車載終端、商用顯示以及投影等跨屏協同場景。在“算、顯”分離領域是少數既掌握核心芯片設計研發技術又掌握智能設備互聯軟件協議的公司，在IC 和應用系統設計方面擁有自己的特色。
海奇產品由多個系列組成：
A系列產品主要應用于多屏互聯、算顯分離領域，該系列產品線也廣泛應用于家庭多媒體播放器、卡拉OK 等產品；
B系列產品主要應用于帶屏類商用顯示產品，包含便攜式播放器、車載多媒體中控、電子賀卡、數碼相框、廣告機、電子水牌、HMI 人機交互等多個領域；
C 系列可應用于對屏幕分辨率要求較高的商顯市場，可支持4K 級解碼和顯示；
D 系列產品支持HDMI 輸入并可驅動RGB/LVDS/MIPI 等主流屏幕接口，可用于投影儀、3D打印、商用電視、專用顯示器等市場；
E 系列是海奇獨有的多顯接口類產品，可在支持HDMI 高清接口輸入輸出的同時，支持主流屏幕輸出接口，典型應用包含卡拉OK 點唱機、會議設備等。
A系列產品
| Part No. | A111 | A210C/A211C | A3000 | A3100 | A3200 | A3300（A300) | A5000 | A5100 | A5200 |
| CPU | 800MHz | 800MHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.2GHz | 1.2GHz | 1.2GHz |
| DRAM | 64MB SIP | ext. max. 256MB @800Mbps | 128MB SiP@1600Mbps | ext. max. 256MB @1333Mbps | ext. max. 256MB @1333Mbps | ext. max. 256MB @1333Mbps | 128MB SiP@1600Mbps | ext. max. 256MB @1333Mbps | ext. max. 256MB @1333Mbps |
| Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI / NAND | SPI Flash | SPI / NAND | SPI Flash | SPI / NAND |
| Video Decoder | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS | H.264@4K 30FPS | |
| Display | HDMI V1.4+VGA | HDMI V1.4 | HDMI_TX/VGA/CVBS | HDMI_TX VGA | HDMI_TX/VGA | HDMI_TX VGA | HDMI_TX/VGA/CVBS | HDMI_TX VGA | HDMI_TX/VGA |
| Video Input | N/A | CCIR601/656 | N/A | N/A | HDMI V1.4 | HDMI1.4 /CVBS | HDMI1.4 /CVBS | N/A | HDMI V1.4 |
| Audio | I2S in+out/SPDIF out | I2S in+out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out |
| USB | USB2.0 | USB2.0 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 |
| HOST/Slavex2 | HOST/Slavex2 | ||||||||
| SDIO | SDIO2.0 | SDIO2.0 | SDIO3.0/eMMC4.4 | SDIO3.0 | SDIO3.0/eMMC4.4 | N/A | SDIO3.0/ EMMC4.4(4line) | SDIO3.0 | SDIO3.0/eMMC4.4 |
| 1data~4Data | 1data~5Data | ||||||||
| I2C/UART | 2xI2C+2xUart, IRRX | 2xI2C+3xUart, IRRX | 2xI2C+2xUart, IRRX | 3xI2C+2xUart,IRRX | 3xI2C+2xUart,IRRX， SAR ADCx2 | 3xI2C+2xUart,IRRX | Support 6xPWM 2xI2C+2xUart, IRRX | 3xI2C+2xUart,IRRX | 3xI2C+2xUart,IRRX， SAR ADCx2 |
| ,4xTPADC, 1xSARADC | |||||||||
| Ethernet | N/A | N/A | Support USB to Ethernet | RMII | RMII | N/A | RMII | RMII | RMII |
| Wi-Fi | A110 Support | A210C Support | Support | Support | Support | Support | Support | Support | Support |
| SW System | RTOS | RTOS | RTOS | Linux/RTOS | Linux/RTOS | Linux/RTOS | RTOS | Linux/RTOS | Linux/RTOS |
| Package | QFN68 | ELQFP128 | QFN68 | eLQFP128 | ELQFP176 | eLQFP128 | eLQFP128/QFN128 | eLQFP128 | ELQFP176 |
B、C系列產品
| Part No. | B100 | B200 | B3100 | B3200 | C3000 | C3100 | C3200 | C5000 | C5200 |
| CPU | 800MHz | 800MHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.2GHz | 1.2GHz |
| DRAM | 64MB SIP | ext. max. 256MB @800MHz | max.256MB ext. | max.256MB ext. | 128MB SiP@1600Mbps | max.256MB ext. | max.256MB ext. | 128MB SiP@1600Mbps | max.256MB ext. |
| 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | |||||
| Flash | SPI Flash | SPI Flash | SPI Flash | SPI / NAND | SPI / NAND | SPI Flash | SPI Flash | SPI / NAND | SPI Flash |
| Video Decoder | Multi-format @FHD 60fps | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS | |
| Display | RGB888+CVBS | RGB888 | RGB565/LVDS/CVBS | RGB888/LVDS/CVBS | RGB565/MIPI/LVDS/CVBS | MIPI/CVBS | RGB888/MIPI/LVDS | RGB565/MIPI/LVDS/CVBS | RGB888/MIPI/LVDS |
| Video Input | CCIR601/656 | CVBS | N/A | CCIR601/CCIR656/ CVBS | CVBS | CCIR601/CCIR656/ CVBS | CCIR601/CCIR656/ CVBS | CCIR601/CCIR656/ CVBS | |
| Audio | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out |
| out/SPDIF out | |||||||||
| USB | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | |
| Host/Slave | Host/Slave | Host/Slave | Host/Slave | Host/Slave | |||||
| SDIO | SDIO2.0 | SDIO2.0 | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/eMMC4.4 | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/eMMC4.4 | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/eMMC4.4 |
| 1data~4Data | 1data~4Data | ||||||||
| I2C/UART | Support 2xI2C+2xUart,support IR receiver | 3xUART,4xTPADC, | 2xI2C+3xUart,T,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | |
| 1xSARADC，IRRX | 1xSARADC | 1xSARADC,IRRX | 2xSARADC IRRX | 2xSARADC IRRX | 1xSARADC,IRRX | 2xSARADC IRRX | |||
| Ethernet | N/A | N/A | N/A | RMII | RMII | N/A | RMII | RMII | RMII |
| Wi-Fi | Support | B200/B200C | Support | Support | Support | Support | Support | Support | Support |
| Support | |||||||||
| SW System | RTOS | RTOS | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux |
| Package | QFN88 | ELQFP128 | eLQFP128 | QFP176 | eLQFP128 | eLQFP128 | eLQFP176 | eLQFP128 | eLQFP176 |
D、E系列產品
| Part No. | D3000 | D3100 | D3101 | D3200 | D5000 | D5200 | E100 | E3000 | E3100 |
| CPU | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.2GHz | 800MHz | 1.2GHz | 1.2GHz |
| DRAM | 128MB SiP@1600Mbps | max.256MB ext. | max.256MB ext. | max.256MB ext. | 128MB SiP@1600Mbps | max.256MB ext. | 64MB SiP@1066Mbps | 128MB SIP@1600Mbps | max.256MB ext. |
| 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | |||||
| Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI / NAND |
| Video Decoder | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS |
| Display | RGB888/MIPI/LVDS/CV BS | RGB565/LVDS | RGB565/LVDS | RGB888/MIPI/LVDS/CV BS | RGB888/MIPI/LVDS/CV BS | RGB888/MIPI/LVDS/CV BS | RGB888/HDMI | HDMI1.4/RGB/MIPI/LV DS | HDMI1.4/RGB888/LVDS |
| /MIPI/VGA | |||||||||
| Video Input | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | N/A | DVP/CSI2.0/HDMI1.4 | |
| /CVBS | |||||||||
| Audio | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+out/SPDIF out | I2S in+I2S out/SPDIF out | I2S/4DMIC in &I2S 7.1 |
| out | |||||||||
| USB | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 HOST/Slavex2 | USB2.0x2 | USB2.0x2 |
| Host/Slave | Host/Slave | Host/Slave | Host/Slave | Host/Slave | Host/Slave | ||||
| SDIO | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO2.0 | SDIO3.0/eMMC4.4 | SDIO3.0/eMMC4.4 |
| I2C/UART | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 2xUART 1xSARADC | Support 6xPWM， 2xUART 1xSARADC | Support 6xPWM， 3xUART, 1xSARADC | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART, 1xSARADC | Support 2xI2C+2xUart,support | Support 6xPWM， 3xUART, 2xSARADC | Support 6xPWM， 3xUART,4xTPADC, |
| 1xSARADC,IRRX | IRRX | IRRX | IRRX | 1xSARADC,IRRX | IRRX | IR receiver | IRRX | 2xSARADC | |
| Ethernet | RMII | N/A | N/A | RMII | RMII | RMII | N/A | N/A | 100/1000M RMII |
| Wi-Fi | Support | Support | Support | Support | Support | Support | Suppport | Support | Support |
| SW | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | ROTS | RTOS/Linux | RTOS/Linux |
| System | |||||||||
| Package | eLQFP128/QFN124 | eLQFP128 | eLQFP128 | eLQFP176 | eLQFP128 | eLQFP176 | QFN124 | eLQFP128 | QFP216 |
珠海海奇半導體產品典型應用
海奇代理商，歡迎咨詢，輔助選型號，提供芯片和方案，還有更多精彩產品方案分享《海奇B3100多媒體應用處理器應用在車載多媒體,網絡數碼相框,網絡廣告機,游戲機,帶屏音響,智能投影儀》《商業顯示-手機同屏器方案》。
